TMC223-SI
Motor Driver/Controller, Stepper, 8V to 29V, 570mA/1 Output, Two Wire Serial Interface, SOIC-20
Image is for illustrative purposes only. Please refer to product description.
ManufacturerTRINAMIC / ANALOG DEVICES
Manufacturer Part NoTMC223-SI
Newark Part No.43AC4084
Also Known AsTMC222-SI
Technical Datasheet
No Longer Available
Product Information
ManufacturerTRINAMIC / ANALOG DEVICES
Manufacturer Part NoTMC223-SI
Newark Part No.43AC4084
Also Known AsTMC222-SI
Technical Datasheet
IC TypeMicrostepping Motor Controller & Driver
Motor TypeTwo Phase Stepper
No. of Outputs1Outputs
Output Current570mA
Output Voltage-
IC Case / PackageSOIC
No. of Pins20Pins
Supply Voltage Min8V
Supply Voltage Max29V
Operating Temperature Min-40°C
Operating Temperature Max125°C
Qualification-
Product Range-
MSL-
SVHCNo SVHC (16-Jul-2019)
Automotive Qualification Standard-
Driver Case StyleSOIC
